Barge Cranes with MAX-AI: The Essential Equipment for Marine Construction
The MAXTECH Grab Barge Crane is a dedicated grab handling solution engineered for high-intensity bulk material transfer where grab performance is the primary priority. Unlike conventional cranes adapted for occasional grab use, this grab crane is optimized from the ground up for continuous grab operation cycles, delivering superior productivity in the most demanding environments.
While versatile enough for barge and shipboard applications, the MAXTECH Grab Crane distinguishes itself through its grab-optimized design — featuring enhanced closing winches, reinforced structure for impact loads, and specialized control algorithms that maximize grab cycle efficiency.
Technical Parameter
Technical Specifications (Model MAX-BGC 200)
| Parameter | Specification |
| Max. Capacity (Grab Operation) | 45 t @ 32 m |
| Max. Capacity (Hook Operation) | 60 t @ 32 m |
| Working Radius (Min. / Max.) | 9 m – 36 m |
| Grab Cycles per Hour | Up to 45 |
| Peak Daily Turnover | 30,000 tons |
| Barge Crane Weight (excl. grab) | Approx. 122 t – 125 t |
| Ambient Working Temperature | -25°C to +45°C |
| Max. Humidity | 93% |
| Max. Wind Speed (Working / Parking) | 20 m/s / 63 m/s |
| Max. Heel / Trim (Grab ≤45 t) | 3° / 2° |
| Drive System | Electric – Three Phase Squirrel Cage |
| Protection Class | IP54 / IP55 |
| Insulation Class | F |
MAX-AI Smart Technology for Barge Cranes
MAXTECH Grab Crane can be equipped with the MAX-AI Smart System, featuring three core modules that ensure safe, efficient, and intelligent operation.
Wire Rope Online Monitoring System
1. Target Component: Hoisting and grab ropes
2. Core Technology: Electromagnetic Non-Destructive Testing (NDT)
3. Functions: Real-time detection of internal/external broken wires, wear, and corrosion; automatic damage reporting and alerting
4. Value: Replaces manual inspection, enables non-stop monitoring, and ensures continuous operational safety for your grab crane
Slewing Bearing Wear Detection System
1. Target Component: Crane slewing bearing
2. Core Technology: High-precision displacement sensors + PLC intelligent analysis
3. Functions: Real-time measurement of bearing settlement (wear); automatic wear trend calculation with out-of-limit alarms
4. Value: Prevents sudden bearing failure, transforming unplanned downtime into scheduled maintenance for your barge crane
Intelligent Anti-Sway & Path Optimization
1. Applications: Ship-to-ship transfer, port unloading from barges, maritime replenishment
2. Dynamic Anti-Sway: Eliminates grab swing in real-time via advanced algorithms
3. AI Path Planning: Automatically optimizes grab trajectories based on historical data
4. Visual Recognition: Identifies barge holds and obstacles to assist precise positioning
5. Edge Computing: Local data processing ensures fast response with low network dependency
6. Safety Protection: Overload / over-moment protection, intelligent anti-collision, and auxiliary operation functions
