In the modern industrial lifting sector, there is an increasingly stringent demand for equipment performance, reliability, and safety. MAXTECH telescopic knuckle offshore cranes have emerged as the top choice for numerous enterprises, thanks to their outstanding parameter specifications, robust performance, and industry - leading certification qualifications.
I. Precise Parameters for Diverse Requirements
MAXTECH telescopic folding cranes come in a wide range of models, with load - bearing capacities spanning from 1 ton to 30 tons. The arm lengths can be flexibly adjusted between 3 meters and 30 meters, meeting the lifting needs of various work scenarios. Take a electric hydraulic marine crane as an example: it can reach a maximum lifting height of 25 meters and a maximum working radius of 20 meters, effortlessly handling complex tasks such as high - rise building construction and large - scale equipment installation. In terms of lifting speed, it can achieve 30 meters per minute when unloaded and maintain an efficient speed of 10 meters per minute when fully loaded, significantly enhancing work efficiency. With a 360° continuous slewing angle, combined with the flexible combination of the folding and telescopic arms, it enables all - around, unobstructed operation. Moreover, the overall dimensions of the cranes have been optimized. The smallest model has an overall width of only 1.2 meters and a height of 2 meters, allowing it to pass through narrow passages with ease, making it suitable for space - constrained work environments.
Main Specification
| Safety Load | Max Outreach | Lifting Speed | Slewing Speed | Luffing Time | Hoisting Height |
| kN | m | m/min | m/min | s | m |
| 10 | 6-20 | 15 | 1 | 60 | 30 |
| 15 | 8-22 | 15 | 1 | 60 | 30 |
| 20 | 5-24 | 15 | 1 | 60 | 30 |
| 30 | 8-25 | 15 | 0.9 | 70 | 30 |
| 50 | 12-25 | 15 | 0.75 | 80 | 30 |
| 80 | 12-25 | 15 | 0.75 | 100 | 40 |
| 100 | 12-25 | 15 | 0.75 | 110 | 40 |
| Above specifications only for reference, We can supply various marine cranes according to your requirements. | |||||
II. Exceptional Performance for Extreme Challenges
(I) Explosion - Proof Performance: Safety Assured
In petroleum and chemical industries' explosive environments, these lift crane explosion - proof features are vital. Advanced tech is integrated, with key electrical and hydraulic components receiving special treatment. Electricals use explosion - proof motors, controllers, and wiring to prevent sparks, while hydraulic pipelines and joints are sealed to avoid oil leaks. Rigorously certified, these cranes operate steadily in explosive gas zones, securing high - risk operations.
(II) Cold - Resistant Performance: Unaffected by Freezing
In frigid polar and high-altitude regions, conventional lifting gear often fails due to cold. MAXTECH knuckle cranes overcome this with specialized design. Our hydraulic systems feature low-temperature oil and heating/insulation, ensuring fluidity at -40°C for normal operation. Crane steel is treated to boost cold toughness and prevent brittleness, while electrical components are cold-resistant, securing reliable performance in icy conditions.
(III) High - Quality Build: Durable and Long - Lasting
MAXTECH upholds stringent quality control during production. Core components like the boom, slewing bearings, and hydraulic pumps are crafted from high - strength alloy steel and sourced from top - tier international suppliers. The booms, welded with high - strength techniques and inspected via rigorous flaw detection, guarantee structural integrity. Precision - engineered, heavy - duty slewing bearings ensure seamless rotations, while the hydraulic pumps leverage advanced international tech for efficiency, energy savings, and longevity. Each crane is outfitted with an intelligent fault diagnosis system, enabling real - time monitoring, early - warning alerts, and prompt maintenance to extend equipment lifespan.
Post time: Jun-13-2025
